Comprehensive sound level measuring
logging for Q-SYS™

SPL Logger Logo - Forward Thinking Designs

SPL Logger is an audio loudness monitoring and logging plugin for QSC® Q-SYS™ DSP systems. Simplify your adherence to occupational safety and health rules as well as organizational policy. Providing real-time and historical loudness data, SPL Logger will make it easier than ever to keep your shows to a safe volume.

SPL Logger is indispensable for theaters, amusement parks, live shows, bars, and restaurants.

Features

Measurements

Calibration procedure built in to the plugin (requires microphone and calibrator, not included).

Linear, A, and C weighting filter options (ANSI S1.42 A and S1.42 C)

  • SPL, Leq 1, and Leq 10 - all the measurements you need to provide a safe environment

    • Leq is the equivalent continuous sound level over a period. You can think of it like an average. SPL Logger provides the equivalent continuous sound level for the last 1 and 10 minutes.

SPL Logger UCI Configuration - Forward Thinking Designs

Graphing

  • Graph the current SPL, Leq 1, and Leq 10 measurements to keep your show right in the sweet spot

  • Each measurement can be turned on independently, and the view scale can be customized

  • Place the graph on your UCI for easy viewing, and customize the colors for use in a dark theater or outdoor festival

  • Set a timer to disable the graph display, or turn off the timeout for constant display

Log Files

  • SPL Logger logs your loudness data to a CSV file so you can review the data at any point in time. Data points are written once per second.

  • 3 different logging modes are offered:

    • Manual mode: Manually enable logging at the start of your event or use the scheduler built in to Q-SYS™ to determine when to log

    • Threshold mode: Set a minimum threshold, and when the sound reaches that level, the plugin begins logging. No need to log loudness overnight when the venue is inactive.

    • Continuous mode: 24/7 SPL logging.

  • Automatic log maintenance: Configure logs to be automatically deleted after a set period of time, from 1 to 365 days

SPL Logger Log (Excel) - Forward Thinking Designs

Limit Thresholds

  • Set maximum limits for SPL, Leq 1, and Leq 10 and get visual feedback when the limit is exceeded. Depending on your needs, these control pins can be tied to a warning light, email notification, or even additional Q-SYS programming.

SPL Logger Logo - Forward Thinking Designs

$250

SPL Logger Logo - Forward Thinking Designs

Comprehensive sound level measuring and logging for Q-SYS™

Main Office

2910 Maguire Road Suite 2008

Ocoee, FL 34761

(407) 850-8093

Satellite Office

1 S. Fair Oakes Ave Suite 207

Pasadena, CA 91105

1-800-484-0383

  • Facebook
  • LinkedIn
  • Instagram
  • Twitter
  • Youtube

SPL Logger is an audio loudness monitoring and logging plugin for QSC® Q-SYS™ DSP systems. Simplify your adherence to occupational safety and health rules as well as organizational policy. Providing real-time and historical loudness data, SPL Logger will make it easier than ever to keep your shows to a safe volume.

SPL Logger is indispensable for theaters, amusement parks, live shows, bars, and restaurants.

Try SPL Logger for yourself! Download the demo here.

GP symbols chunk-01.png

Features

Measurements

  • SPL, Leq 1, and Leq 10 - all the measurements you need to provide a safe environment.

    • Leq is the equivalent continuous sound level over a period. You can think of it like an average. SPL Logger provides the equivalent continuous sound level for the last 1 and 10 minutes.

  • Linear, A, and C weighting filter options (ANSI S1.42 A and S1.42 C).
  • Calibration procedure built in to the plugin (requires microphone and calibrator, not included).
SPL Logger UCI Configuration - Forward Thinking Designs

Graphing

  • Graph the current SPL, Leq 1, and Leq 10 measurements to keep your show right in the sweet spot.

  • Each measurement can be turned on independently, and the view scale can be customized.

  • Place the graph on your UCI for easy viewing, and customize the colors for use in a dark theater or outdoor festival.

  • Set a timer to disable the graph display, or turn off the timeout for constant display.

Log Files

  • SPL Logger logs your loudness data to a CSV file so you can review the data at any point in time. Data points are written once per second.

  • 3 different logging modes are offered.

    • Manual mode: Manually enable logging at the start of your event or use the scheduler built in to Q-SYS™ to determine when to log.

    • Threshold mode:  Set a minimum threshold, and when the sound reaches that level, the plugin begins logging. No need to log loudness overnight when the venue is inactive.

    • Continuous mode: 24/7 SPL logging.

  • Automatic log maintenance: Configure logs to be automatically deleted  after a set period of time, from 1 to 365 days.

SPL Logger Log (Excel) - Forward Thinking Designs

Limit Thresholds

  • Set maximum limits for SPL, Leq 1, and Leq 10 and get visual feedback when the limit is exceeded. Depending on your needs, these control pins can be tied to a warning light, email notification, or even additional Q-SYS programming.

*One SPL Logger license can be used for up to 3 instances of the plugin on a single Q-SYS™ core. There is no limit to the number of instances that can be run on a single core.

Who might need SPL Logger?

SPL Logger is a tool to assist in maintaining compliance with safety and health rules concerning sound levels. Themed entertainment, houses of worship, lecture halls, and other large venues come to mind.

System Requirements
  • Q-SYS Core running Q-SYS v7.0.0 or later. Cores running Q-SYS v9.0 or later require SPL Logger to be updated to v1.1.0.

  • Q-SYS v8.1.1 or later is required to display the graph. SPL Logger will run on v7.0.0-8.0.0 but will not display the graph.

  • ​Use of User Control Interfaces requires a Q-SYS™ Core UCI Deployment Software License.

  • Measurement microphone

    • Microphone calibrator (recommended)

How is SPL Logger licensed?
  • One SPL Logger license can be used for up to 3 instances of the plugin on a single Q-SYS™ Core.

  • There is no limit to the number of instances that can be run on a single core.

  • All future updates are included.

Does SPL Logger need internet access?

No.

Is there a trial version of SPL Logger?

Yes. SPL Logger can be used in demo mode for 10 minutes to evaluate the plugin. The 10 minute period can be restarted by restarting the Q-SYS™ design. Use of the plugin in demo mode for commercial purposes is prohibited.

Downloads

Proud IAAPA member - Forward Thinking Designs
Proud AVIX member - Forward Thinking Designs
Proud Themed Entertainment Association (TEA) member - Forward Thinking Designs
Proud Q-SYS Developer Partner - Forward Thinking Designs
System Requirements
  • Q-SYS Core running Q-SYS v7.0.0 or later. Cores running Q-SYS v9.0 or later require SPL Logger to be updated to v1.1.0.

  • Q-SYS v8.1.1 or later is required to display the graph. SPL Logger will run on v7.0.0-8.0.0 but will not display the graph.

  • ​Use of User Control Interfaces requires a Q-SYS™ Core UCI Deployment Software License

  • Measurement microphone

    • Microphone calibrator (recommended)

Who might need SPL Logger?

SPL Logger is a tool to assist in maintaining compliance with safety and health rules concerning sound levels. Themed entertainment, houses of worship, lecture halls, and other large venues come to mind.
